UndecidedPoints

The prompt for Genuary 2024 Day 8 is Chaotic Systems, Day 22 is Point-Line-Plane and Day 24 is Undecided Geometry

The Chaotic systems can be heard through the sound design in this SonicPi Coded Composition. To reinforce the chaotic system, usage of geometric and linear algebra equations were used to control the sound.

The Point to Plane and Line to Plane equations were the linear algebra components used to create the sound. Then an assortment of those return values were then integrated in the circumference equation to bring a sense of undecided geometry.

Audio

IllestPreacha · Undecided Points

Poetry

Points to Plane
Line not knowing to stay
Undecided
But reminded
That the path isn’t only the plane
So, Chaotic they get
Chaotic in depth

SonicPi Code

#linear algebra - point to a plane forumla

# distance between point and
# plane is: d = |Axo + Byo + Czo + D |/√(A**2 + B**2 + C**2)

#pt_$ = variable for points
#pl_$ = variable for plane



def pointToPlane (pt_a,pt_b,pt_c, pl_a,pl_b,pl_c,pl_d)

  use_random_seed (Time.now.to_i)/5

  point_a = [pt_a,pt_b,pt_c]
  plane_a = [pl_a,pl_b,pl_c,pl_d]

  #dot product of the point and planes
  dot = point_a[0]*plane_a[0] + point_a[1] * plane_a[1] + point_a[2] * plane_a[2] + plane_a[3]

  #the distance of the point to plane
  return plane_D = dot / Math.sqrt(plane_a[0] ** 2 + plane_a[1] ** 2 + plane_a[2] ** 2)

  #puts plane_D
end

def lineToPlane(xt,yt,zt, pl_a,pl_b,pl_c,pl_d)

  use_random_seed (Time.now.to_i)/4

  t = 0

  # line to point
  point_a = [xt + t,yt * t + yt,zt * 2]

  plane_a = [pl_a,pl_b,pl_c,pl_d]

  #dot product of the point and planes
  dot = point_a[0]*plane_a[0] + point_a[1] * plane_a[1] + point_a[2] * plane_a[2] + plane_a[3]

  #the distance of the point to plane
  return plane_D = dot / Math.sqrt(plane_a[0] ** 2 + plane_a[1] ** 2 + plane_a[2] ** 2)

  #puts plane_D
end

#the rate of the loops are determined by the distance to the plane
#as well as the sustain length


live_loop :lineToPlaneDistance do
  use_random_seed (Time.now.to_i)/2
  speed = lineToPlane(dice(5),dice(9),rrand_i(1,12),dice(10),8,rrand_i(-4,4),[0,1,2,3,4].choose)
  sample [:loop_perc1,:ambi_dark_woosh].choose, rate: speed + 0.1, sustain: speed, amp: dice(5)
  sleep [0.5,1,1.5,2,4].choose
end


live_loop :pointToPlaneDistance do
  use_random_seed (Time.now.to_i)
  speed = pointToPlane(dice(3),dice(4),rrand_i(0,3),dice(10),8,rrand_i(-4,4),[0,1,2,3,4].choose)
  speed2 = pointToPlane(rrand_i(0,3),5,dice(4),dice(10),rrand_i(-4,4),9,[0,1,2,3,4].tick)
  sample [:loop_electric,:elec_chime].choose, rate: speed, sustain: speed2, amp: dice(5)
  sleep [0.5,1,1.5,2].choose
end


live_loop :DistanceToDistance do
  use_random_seed (Time.now.to_i)/3

  speed = pointToPlane(dice(3),dice(4),rrand_i(0,3),dice(10),8,rrand_i(-4,4),[0,1,2,3,4].choose)
  speed2 = lineToPlane(rrand_i(0,3),5,dice(4),dice(10),rrand_i(-4,4),9,[0,1,2,3,4].tick)

  #undecided geometry
  distToDist = speed + speed2
  distXdist = speed * speed2
  dist_dist = speed / speed2

  #points into circle
  circumference = (2 * Math::PI * ([distToDist,distXdist,dist_dist].choose)).abs
  area = Math::PI * (distToDist ** 2)

  play [circumference,circumference/2], decay: rrand(1,4)
  sample [:ambi_drone,:elec_beep,:drum_splash_hard,:guit_em9].choose, beat_stretch: area / 80

  sleep [0.5,1,1.5,2,4].choose
end
